Powder Coating

Powder Coating is an important surface treatment technology. It is a surface treatment technology that evenly sprays fine powder paint on the surface of metal, aluminum, stainless steel and other objects, and then bakes it at high temperature to form a protective layer with corrosion resistance, wear resistance and aesthetic performance.

Contact Message

Data sheet of Powder coating

1.Powder coating thickness: 60-120μm, adjustable.

2.Fluidizing pressure: 0.05MPa

3.Atomization pressure: 0.05MPa

4.Powder spraying pressure: 0.2-0.5MPa, adjustable.

5.Average particle size of powder coating: 30~50μm

6.Powder resistivity: 1010 ~1012Ω.m

7.Powder particle size: It is recommended to use 20-80 mesh powder particles. customizable.

8.Spray gun distance: 200-250mm

9.Spraying temperature: 20-30°C

10.Spray humidity: less than 85%

11.Curing process process parameters: baking temperature (furnace temperature) 200 ° C, heating time (from entering the furnace to leaving the furnace) 30 minutes.

12.The method of optimizing the best curing conditions: Orthogonal test method

13.Standard: GB/T5237.4--2000
